FEATURES
- 12” low distortion cast frame woofer.
- 2” titanium compression driver.
- 2 x Parallel Speakon Inputs.
- Rhino Rock textured black paint finish.
- Plywood construction.
- Steel grille.
- 2 x 4-way high impact plastic handles.
DESCRIPTION:
Delta 12 is a mid-sized passive speaker, whilst coming in slightly smaller compared with the 15” model the speaker offers a confident full-range sound. Featuring a 2” titanium voice coil combined with a 12” low distortion cast frame woofer, the loudspeaker generates 400 watts RMS of power while the 90 x 60 waveguides ensure a long-throw projection.
SPECIFICATION
| Configuration | 2-Way |
| Frequency Response ( /- 3dB) | 60Hz – 20KHz |
| Power (RMS / Program / Peak) | 400W / 800W / 1600W |
| Impedance | 8Ω |
| Max SPL | 129dB |
| Low Frequency Transducer | 12″ |
| High Frequency Transducer | 2″ Titanium Compression Driver |
| Nominal Coverage | 90° x 45° |
| Waveguide Type | Elliptical |
| Input | 2 x Speakon |
| Net Weight | 23.18kg / 50.9lbs |
| Gross Weight | 28.5kg / 62.8lbs |
| Dimensions (H x W x D) | 449mm x 390mm x 618mm |
